| item # |
part # |
description> |
qty req'd |
price |
add to cart |
| 1B |
65267 |
DRIVE CAP - BLACK |
1 |
$4.95 |
 |
1B |
64913 |
DRIVE CAP - BLACK |
1 |
$4.95 |
|
3 |
27198 |
MOTOR FRAME CLIP |
1 |
$1.50 |
|
5 |
22682 |
SWITCH AND CIRCUIT BOARD ASSEMBLY |
1 |
$10.25 |
|
6 |
27352 |
MAGNETIZED FIELD ASSEMBLY |
1 |
$25.95 |
|
8 |
64965 |
INSULATOR |
1 |
$1.70 |
|
9A |
22267 |
HANGER BAIL (FOR UNITS AFTER 7/3/03) |
1 |
$1.95 |
|
9B |
25061 |
BAIL HOOK (FOR UNITS BEFORE 7/3/03) |
1 |
$0.99 |
|
12 |
64606 |
FRONT HOUSING SCREW |
1 |
$0.75 |
|
13A |
28194 |
HINGE ASSEMBLY BGC |
1 |
$7.25 |
|
14 |
27861 |
BLADE HINGE SCREW |
1 |
$0.75 |
|
15 |
27847 |
CARBON BRUSH WITH SHUNT |
1 |
$1.65 |
|
16 |
64003 |
BLADE BRACKET |
2 |
$2.55 |
|
17 |
64139 |
BLADE SCREW |
1 |
$0.75 |
|
18 |
64027 |
BLADE GUIDE |
1 |
$1.95 |
|
20 |
21977 |
ARMATURE ASSEMBLY |
2 |
$49.95 |
|
21 |
27854 |
CAM AND BEARING ASSMELBY |
2 |
$15.95 |
|
22 |
20168 |
LARGE BEARING CUP |
1 |
$1.95 |
|
23 |
65013 |
FRONT MOTOR FRAME |
2 |
$4.95 |
|
24 |
S20651 |
BLADE DRIVE ASSEMBLY |
1 |
$3.95 |
|
25 |
15766 |
BLADE DRIVE SCREW |
1 |
$0.70 |
|
27 |
26049 |
CORD SET |
1 |
$8.00 |
|
28 |
21067 |
SMALL BEARING CUP |
1 |
$1.50 |
|
29 |
65806 |
BRUSH SPRING |
1 |
$0.99 |
|
30 |
64991 |
OIL SEAL |
1 |
$0.95 |
|
31 |
17091 |
SELF-ADHESIVE FOAM PAD |
1 |
$1.50 |
|
