| item # |
part # |
description> |
qty req'd |
price |
add to cart |
| 2A |
63953 |
UPPER HOUSING (METALLIC BLUE) |
1 |
$6.95 |
 |
3A |
22449 |
DRIVE CAP (METALLIC BLUE) |
1 |
$4.95 |
|
4 |
64902 |
SWITCH BUTTON |
1 |
$2.25 |
|
5 |
64794 |
SWITCH BUTTON LOCK |
1 |
$2.90 |
|
6 |
64788 |
SWITCH BUTTON RETAINER |
1 |
$2.95 |
|
7 |
64527 |
LOCK RING |
1 |
$1.75 |
|
10 |
65013 |
FRONT MOTOR FRAME |
1 |
$4.95 |
|
11 |
21067 |
SMALL BEARING MOUNTING RING |
1 |
$1.50 |
|
12 |
64507 |
SWITCH |
1 |
$6.95 |
|
14 |
64503 |
COPPER BRUSH WITH SHUNT |
2 |
$1.95 |
|
15 |
65806 |
BRUSH SPRING |
2 |
$0.99 |
|
17 |
64514 |
MOTOR FRAME CLIP |
2 |
$1.50 |
|
18 |
64726 |
ARMATURE ASSEMBLY |
1 |
$35.96 |
|
19 |
27251 |
CAM ASSEMBLY |
1 |
$9.95 |
|
20 |
64860 |
MAGNETIZED FIELD ASSEMBLY |
1 |
$8.95 |
|
21 |
15766 |
SCREW, 4-40 X 7/32 |
2 |
$0.70 |
|
22 |
S20651 |
BLADE DRIVE ASSEMBLY |
1 |
$5.50 |
|
23 |
21068 |
LARGE BEARING MOUNTING RING |
1 |
$1.95 |
|
24 |
64027 |
BLADE GUIDE |
1 |
$1.95 |
|
26 |
64139 |
BLADE SCREW |
2 |
$0.75 |
|
27 |
64003 |
BLADE BRACKET |
1 |
$2.55 |
|
28 |
64784 |
O-RING |
1 |
$1.50 |
|
29 |
64535 |
LOCK KEEPER |
1 |
$2.25 |
|
30 |
64537 |
BLACK LOCK |
1 |
$0.95 |
|
31 |
27861 |
SCREW, BLADE HINGE |
2 |
$0.75 |
|
32 |
S63897 |
HINGE ASSEMBLY |
1 |
$5.95 |
|
33 |
64606 |
HOUSING SCREW |
4 |
$0.75 |
|
34 |
63075 |
CORDED ADAPTOR |
1 |
$29.95 |
|
35A |
64754 |
FOAM PAD |
1 |
$0.99 |
|
36 |
64916 |
OIL SEAL |
1 |
$0.95 |
|
